| Specification | Description |
|---|---|
| Chipset | Intel Q170 PCH-H vPro |
| Processors |
|
| Specification |
|---|
| Intel HD graphics on all models (integrated on processor) |
| Specification | Description |
|---|---|
| DDR4-2400 | Maximum: 64 GB Number of slots: (4) DIMM (both slots are customer accessible/upgradeable) Up to 2400 MT/s) |
| Specification | Description |
|---|---|
| SATA drives | 2.5 inch 5.4k RPM Hard Disk Drives 2.5 inch 7.2k RPM Hard Disk Drives Optical Disc Drives |
| Specification | Description |
|---|---|
| Type | Integrated |
| HD stereo codec | Realtek 2-channel ALC221 codec |
| Audio I/O ports | Front microphone-in (150-K ohm input impedance) Rear Line-In/Microphone input (150-K ohm input impedance, function is configurable by audio driver) Rear Line-Out* (190 ohms Output Impedance, expects at least a 10-K ohm load) Front Headphone-Out (0.5 Ohm Output Impedance, expects at least a 32 ohm load) Front Microphone/Headphone jack is re-task able to provide Microphone input, line-in or Headphone output to support connecting two headphones to the front of the system. When configured as a second front headphone output, both front headphone outputs are always driven with the same signal. All ports are 3.5 mm |
| Internal speaker amplifier | 1.5 W amplifier for the internal speaker only. External speakers must be powered externally. Rear Line-in audio port is re-taskable as either Line-in or Microphone-in. |
| Multi-streaming capable | 8 kHz - 192 kHz |
| Sampling | Multi-streaming can be enabled in the Realtek control panel to allow independent audio streams to be sent to and from the front and rear jacks. |
| Wavetable syntheses | Yes - Uses OS soft wavetable |
| Analog audio | Yes |
| Number of channels on Line-Out | Stereo (Left and right channels) |
| Internal speaker | Yes |
| External speaker jack | Yes |
| Specification | Description |
|---|---|
| Ethernet (RJ-45) |
| Specification | Description |
|---|---|
| Preinstalled OS | Windows 10 Pro 64 Windows 10 Home 64 Windows 8.1 Pro (64-bit) Windows 8 .1 (64-bit) Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) Windows 7 Professional 32 (available through downgrade rights from Windows 10 Pro) FreeDOS 2.0 |
